- Parameters
- Dimensions
- Download
- Customization
| Housing Dimensions | 168*1050mm |
| Power Voltage: | 220V±10% 50Hz |
| Power Consumption (W): | 40～70W |
| Operation Condition: | -15℃～70℃ |
| Housing Thickness: | 0.8mm+1.0mm |
| Body Material: | SUS304 + Acrylic |
| Motor: | DC24V Brushless Electric Motor |
| IP Degree: | IP54 |
| Life Cycle: | 6 Million Times |
| Operating Humidity | 20%~95% No Condensation |
| Flow Rate : | 25-40 People Per Minute |
| Width of Passage | 600mm(Customizable Max 700mm) |
| Infrared sensor： | 0 Pairs |
| Traffic Flow Applicable: | 110V～240V |
| Net Weight： | Double Core: 15.5Kg Single Core: 12.5Kg |
| Gross Weight: | Double Core: 18.5Kg Single Core: 21.5Kg |
| Communication: | RS485 RS232/Dry Contact |
