| Housing Dimensions | 1200*185*1020mm |
| Power Voltage: | 220V±10% 50Hz |
| Power Consumption (W): | 40～70W |
| Operation Condition: | -15℃～70℃ |
| Housing Thickness: | 1.2mm+1.0mm |
| Body Material: | SUS304 + Acrylic + Tempered Glass |
| Motor: | DC24V Brushless Electric Motor |
| IP Degree: | IP54 |
| Life Cycle | 8 Million Times |
| Operating Humidity： | 20%~95% No Condensation |
| Flow Rate : | 25-40 People Per Minute |
| Width of Passage： | 600mm(Customizable Max850mm) |
| Infrared sensor： | 4 Pairs |
| Traffic Flow Applicable: | 110V～240V |
| Net Weight： | Double Core: 45Kg Single Core: 38Kg |
| Gross Weight: | Double Core: 48Kg Single Core: 41Kg |
| Communication: | RS485 RS232/Dry Contact |
