| Housing Dimensions | 380*300*1024mm |
| Power Voltage: | 220V±10% 50Hz |
| Power Consumption (W): | 40～70W |
| Operation Condition: | -15℃～70℃ |
| Housing Thickness: | 1.2mm |
| Body Material: | Painted Carbon Steel+ Acrylic + Tempered Glass+SUS304 |
| Motor: | DC24V Brushless Electric Motor |
| IP Degree: | IP54 |
| Life Cycle | 8 Million Times |
| Operating Humidity: | 20%~95% No Condensation |
| Flow Rate : | 25-40 People Per Minute |
| Width of Passage: | 600mm(Customizable Max850mm) |
| Infrared sensor | 2 Pairs |
| Traffic Flow Applicable: | 110V～240V |
| Net Weight： | Double Core: 30Kg Single Core: 27Kg |
| Gross Weight: | Double Core: 33Kg Single Core: 30Kg |
| Communication: | RS485 RS232/Dry Contact |
