| Housing Dimensions | 1200*140*1000mm |
| Power Voltage: | 220V±10% 50Hz |
| Power Consumption (W): | 40～70W |
| Operation Condition: | -15℃～70℃ |
| Housing Thickness: | 1.0mm+0.8mm |
| Body Material: | SUS304 + Acrylic + Tempered Glass |
| Motor: | DC24V Brushless Electric Motor |
| IP Degree: | IP53 |
| Life Cycle | 6 Million Times |
| Operating Humidity: | 20%~95% No Condensation |
| Flow Rate : | 25-40 People Per Minute |
| Width of Passage: | 600mm(Customizable Max800mm) |
| Infrared sensor | 4 Pairs |
| Traffic Flow Applicable: | 110V～240V |
| Net Weight： | Double Core:38Kg Single Core: 35Kg |
| Gross Weight: | Double Core: 42Kg Single Core: 38Kg |
| Communication: | RS485 RS232/Dry Contact |
