| Housing Dimensions | 1400*300*980mm |
| Power Voltage: | 220V±10% 50Hz |
| Power Consumption (W): | 40～70W |
| Operation Condition: | -15℃～70℃ |
| Housing Thickness: | 1.5mm+1.0mm |
| Body Material: | SUS304+Painted Carbon Steel+ Acrylic + Tempered Glass |
| Motor: | DC24V Brushless Electric Motor |
| IP Degree: | IP52 |
| Frequency: | 9 Million Times |
| Infrared sensor | 3 Pairs |
| Traffic Flow Applicable: | 110V～240V |
| Operating Humidity: | 20%~95% No Condensation |
| Flow Rate : | 30-45 People Per Minute |
| Width of Passage: | 550mm |
| Net Weight： | Double Core: 44Kg Single Core: 34Kg |
| Gross Weight: | Double Core: 48Kg Single Core: 38Kg |
| Communication: | RS485 RS232/Dry Contact |
